Purtrex*
FACT SHEET
Melt blown depth filter for general industrial use
Features and Benefits
• Exceptional value for general applications
• Progressive graded density captures particles
throughout the entire filter
• Long life and lower change-out frequency
• Exceptional dirt holding capacity
• Pure polypropylene construction
• No wetting agents, solvents, antistatic agents, or
binders
• Made with 90% to 100% pre-consumer recycled
polypropylene material to reduce landfill waste
• Meets FDA requirements for food and beverage
contact
• Made in the USA
Applications
• General industrial use
• Potable water filtration
• Chemical filtration
• Plating baths
• Amine filtration
Specifications
Table 1: Specifications and performance information
Ratings | 1, 3, 5, 10, 20, 30, 50, 75 microns
(nominal) |
Inner Diameter (nominal) | 1 in (2.5 cm) |
Outer Diameter | 2.5 in (6.4 cm) |
Lengths | |
9 3/4 in (24.8 cm) | 29 1/4 in (74.3 cm) |
10 in (25.4 cm) | 30 in (76.2 cm) |
19 1/2 in (49.5 cm) | 40 in (101.6 cm) |
20 in (50.8 cm) | 50 in (127.0 cm) |
Longer lengths up to 70 in may be available upon request | |
Materials of Construction | |
Filter Media | Polypropylene |
Adapters | Polypropylene |
Elastomer | Buna, EPDM, Silicone, Viton 1
Santoprene 2 (flat gasket only) |
Performance Conditions | |
Maximum Pressure Drop | 35 psid (2.4 bar) @ 100°F (38°C) |
Recommended Change-Out Pressure Drop: |
20 psid (1.4 bar) @ 77°F (25°C) |
Efficiency Information
Table 2: Removal efficiency based on a modified
ASTM 795 test procedure
Micron Rating |
Removal rating (µm) at various efficiencies | ||
90.0% | 99.0% | 99.9% | |
1 µm |
Efficiency of nominal filters varies by application. See note for information on nominal filter efficiency. 3 |
||
3 µm | |||
5 µm | |||
10 µm | |||
20+ µm |
Graph 1: Purtrex clean water flow rate based on a 10 in length filter
Quality
Purtrex filters are manufactured under a quality management system that has been certified to meet ISO 9001 standards. Each filter is assigned a lot code to ensure traceability of the data and materials used in the manufacturing process.
Certifications
• U.S. FDA 21CFR 177.1520 food contact
requirements
• Article 3 of the EU Framework Regulation No.
1935/2004/EC safety requirements
• EU Plastics Regulation No. 10/2011 (may be
used as intended in compliant EU Member
states)
• USP class VI-121°C Plastics criteria
• NSF 61 criteria
• ISO 9001 criteria
Veolia filter cartridges are designed and
manufactured for resistance to a wide range of
chemical solutions. Conditions will vary with each
application and users should carefully verify chemical
compatibility. Please contact your Veolia
representative for more information.
Ordering Information
Replace the numbers with your desired values from
each column. Columns 3, 4, and 5 are optional
depending on the desired configuration. Use “-B” if
you would like bulk packaging.
Example: PX 05-40-EHB
1 | 2 | 3 | 4 | 5 | |
Type |
Micron Rating (nominal) |
Cartridge Length |
End #1 Adapter |
End #2 Adapter |
Elastomer Material |
PX | 01 = 1 µm
03 = 3 µm 05 = 5 µm 10 = 10 µm |
9 3/4 in (24.8 cm)
10 in (25.4 cm) 19 1/2 in (49.5 cm) 20 in (50.8 cm) |
E = 222 O-Ring
L = Extended Core |
H = Fin
K = Self Seal Spring
S = Solid End Y = Flat gasket |
B = Buna E = EPDM
P = Santoprene 2 (flat gasket only) |
20 = 20 µm
30 = 30 µm |
29 1/4 in (74.3 cm)
30 in (76.2 cm) |
X = Standard Plain End (no gasket) | S = Silicone
V = Viton 1 |
||
50 = 50 µm | 40 in (101.6 cm) | ||||
75 = 75 µm | 50 in (152.4 cm) | Y = Flat Gasket | |||
Longer lengths up to 70 in may be available upon request |
1 Viton is a registered mark of The Chemours Company.
2 Santoprene is licensed to Advanced Elastomer Systems, L.P.
3 Absolute-rated filters have been designed and tested to reject at least 99% of particles of the listed micron size. Nominal-rated filters have a wider
distribution of pore sizes and therefore a wider distribution of rejected particle sizes. The nominal rating is primarily used to compare efficiencies
across a filter family and between filter manufacturers. Efficiency is dependent on particle shape, size, composition, application, and testing protocol.
